2 pcs x Celestion TF0615 6-inch 6.5-inch Midrange Speaker 100W-RMS/200 Watt 8ohm
2 pcs x Celestion TF0615 6-inch 6.5-inch Midrange Speaker 100W-RMS/200 Watt 8ohm
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Compatible Brand | Universal |
| Brand | Celestion |
| Type | Woofer |
| Unit Type | Unit |
| Size | 6.5" |
| Country/Region Of Manufacture | China |
Celestion TF0615 6" 100 Watt Professional Woofer Driver 8 Ohm The versatile Celestion TF0615 6" driver offers excellent performance when used in bass and dedicated midrange applications. Its 1.5" copper voice coil is set onto a polyimide former, which assures good long-term resistance to the detrimental effects of extreme high temperatures. A cloth sealed surround is combined with an optimized Kevlar-loaded paper cone, to ensure the speaker's frequency response is smooth and extended. An intelligent heat vented motor assembly enhances cooling, and a rigid chassis design for maximum energy transfer. Product Specifications Nominal Diameter 6"/6.5"Power Handling (RMS) 100 WattsPower Handling (max) 200 WattsImpedance 8 ohmsFrequency Response 85 to 6,000 HzSensitivity 95 dB 1W/1mVoice Coil Diameter 1.5"Magnet Weight 17 oz. Thiele-Small Parameters Resonant Frequency (Fs) 107.2 HzDC Resistance (Re) 7.25 ohmsMechanical Q (Qms) 5.83Electromagnetic Q (Qes) 0.68Total Q (Qts) 0.61Compliance Equivalent Volume (Vas) 0.23 ft.³Mechanical Compliance of Suspension (Cms) 0.19 mm/NBL Product (BL) 9.03 TmDiaphragm Mass Inc. Airload (Mms) 11.39gMoving Mass Of Diaphragm (Mmd) 11.31 gMaximum Linear Excursion (Xmax) 2.50 mmSurface Area of Cone (Sd) 188 cm² Materials of Construction Cone Material Paper / KevlarSurround Material ClothVoice Coil Wire Material CopperVoice Coil Former Kapton® / PolyimideBasket / Frame Material SteelMagnet Material Ferrite Mounting Information Overall Outside Diameter 7.01"Baffle Cutout Diameter 5.79"Depth 2.91"Bolt Circle Diameter 6.63"# Mounting Holes 4Optimum Cabinet Size (determined using BassBox 6 Pro High Fidelity suggestion) Sealed Volume 0.33 ft.³Sealed F3139 HzVented Volume 0.56 ft.³Vented F365 Hz
